ANPR & Traffic Enforcement
Red light violations, illegal turning, driving in the wrong lanes and speeding are the main causes of fatal road traffic accidents, especially at junctions.
Red light violations, illegal turning, driving in the wrong lanes and speeding are the main causes of fatal road traffic accidents, especially at junctions.
Equipment
Functionality
Key features
System design
Violations enforcement
Accessories
Patrol edition
Factor. All in one unit for traffic monitoring system
All in One Unit is a convenient, advanced and easy to install solution for street photo and video detection of traffic enforcement.
Factor works in stationary mode, in portable mode and in motion mode when installed on a moving patrol car
Download datasheets<<
Factor works in stationary mode, in portable mode and in motion mode when installed on a moving patrol car
Download datasheets<<
Functionality
- Fully automatic operation for vehicle control on up to 6-8 traffic lanes simultaneously in both directions.
- Speed measurement range 0-350 km/h
- Automatic number plate recognition of various countries and vehicle classification
- Collections major traffic statistics including the number of vehicles, the minimal, maximum and average speed, plus average traffic density
- Real-time matching of licence plates against law enforcement databases
- Exports data to law enforcement centers automatically
Key features
Radar and Optical speed measuring technology
Advanced Video Analytics
Data protection from unauthorized access
Easy setup and calibration
Works autonomously 24/7
Mounts on existing light poles, gantries and other suitable structures
Vehicle Classification (bikes, cars, buses, large trucks)
Detects 15 types of traffic violations
Detects pedestrians and objects on the roads
Over 98% recognition with less than 2% missed at nighttime and daytime, in all weather conditions
Advanced Video Analytics
Data protection from unauthorized access
Easy setup and calibration
Works autonomously 24/7
Mounts on existing light poles, gantries and other suitable structures
Vehicle Classification (bikes, cars, buses, large trucks)
Detects 15 types of traffic violations
Detects pedestrians and objects on the roads
Over 98% recognition with less than 2% missed at nighttime and daytime, in all weather conditions
Factor includes
- specified video camera with a lens
- infrared illumination components (illuminator)
- a GLONASS/GPS receiver
- a computing module
- switchgear and power supply equipment
- radar (option speed estimation)
Types of detected violations
- Speed violations: instantaneous and average
- Speed limits for each traffic lane
- Passing a red light
- Crossing of the stop line
- Prohibited L turn, U turn
- Lane changing violations
- Yellow Box violation on intersection
- Stop at the crosswalk
- Parking violations
- Driving to oncoming traffic lane
- Violations on the railway crossings
- Prohibited driving in reverse and more
Portable FACTOR All in One Unit includes following accessories:
Tripod
Swing mechanism
Battery Box
Wi-Fi/LTE Router (installed in the battery box)
Carrying case
A battery and a laptop computer may be optionally included
Tripod
Swing mechanism
Battery Box
Wi-Fi/LTE Router (installed in the battery box)
Carrying case
A battery and a laptop computer may be optionally included
The unit is mounted in a LED light bar or a light box on the roof of a patrol car. The device may be operated on a moving or a stationary vehicle
Equipment
Functionality
Key features
System design
Violations enforcement
Accessories
MicroCyclops. All in one unit for traffic monitoring system
All in One Unit is a convenient, advanced and easy to install solution for street photo and video detection of traffic enforcement.
MicroCyclops are available in stationary and portable versions.
Download datasheets<<
MicroCyclops are available in stationary and portable versions.
Download datasheets<<
Functionality
- Automatic license plate recognition
- Detection, photo and video recording of over 15 types of violations
- Location detection, vehicle path and speed recognition, average speed measurementRecording and archiving information about every vehicle passing
- Real time license plate matching against police databases
- Automatic data export to police data centers
- Traffi c statistics collection: quantity of vehicles, minimum, maximum, average speed,
- as well as average traffic density
- Data protection against unauthorized access: electronic digital signature, user logging activity control
Key features
- High recognition accuracy
- Low percentage of missed vehicles
- Setting speed limits for each lane and various types of vehicles (large trucks, passenger cars, buses)
- Simple mounting and maintenance
- Low power consumption
- Operation in any weather conditions: from -50°C to 50°C
- Solid light single unit and compact size
- Original auto calibration and auto adjustment technology
System includes
- video camera with a lens
- infrared illumination components (illuminator)
- GLONASS/GPS receiver, a multi-target radar
- computing module
- switchgear and power supply equipment.
Types of detected violations
- peed violations: instantaneous speed and average speed detection on the road with speed limits for each traffi c lane (optional)
- Intersection crossing violations: running a red light, illegal L-turn and U-turn, failure to stop at a crosswalk, or a stop line
- Railway crossing violations
- Wrong-way driving
- Parking violations
- Driving on a designated lane (i.e. bus lane)
- Compatible with vehicle weight control system
MicroCyclops D50M25E351M All in One Unit (portable version) includes following accessories:
- Tripod
- Swing mechanism
- Battery Box
- Wi-Fi/LTE Router (installed in the battery box)
- Carrying case
Equipment
Functionality
System design
Switchboard cabinet
SMCross2 220
SMCross2 220
SMCross2 220 switchboard cabinet is designed to ensure user-friendly and interference immune switching operations of outdoor traffic monitoring (photo and video recording equipment and other check point equipment) and other video surveillance systems.
For external connected equipment, the cabinet is a stabilized power source with a controlled switchgear.
For external connected equipment, the cabinet is a stabilized power source with a controlled switchgear.
SMCross2 220
The structure is vibration and impact resistant. The housing is dust and moisture proof, the door is closed tightly. An integrated temperature regulation system ensures overheating compensation. Bottom panel of the cabinet has a door with cable glands for connecting cables from external check point devices and networks.
Switching and control check point equipment, a fan and a power source are located inside the housing and on the door. Inner equipment is securely fixed on DIN-rails and special brackets, all the necessary switching between the inner connectors is provided. All electric and telecommunication connections run through corresponding leakage current, overvoltage, short circuit and surge voltage (lightning) protection devices.
An internal cabinet controller is provided to control the operating capacity of the inner and outer devices and to remotely power them on and off.
Switching and control check point equipment, a fan and a power source are located inside the housing and on the door. Inner equipment is securely fixed on DIN-rails and special brackets, all the necessary switching between the inner connectors is provided. All electric and telecommunication connections run through corresponding leakage current, overvoltage, short circuit and surge voltage (lightning) protection devices.
An internal cabinet controller is provided to control the operating capacity of the inner and outer devices and to remotely power them on and off.
Equipment
Functionality
System design
Switchboard cabinet
SSCross2 POE 220
SSCross2 POE 220 switchboard cabinet is designed to ensure user-friendly and interference immune switching operations of outdoor traffic monitoring (photo and video recording equipment and other check point equipment) and other video surveillance systems.
For external connected equipment, the cabinet is a stabilized power source with a controlled switchgear.
For external connected equipment, the cabinet is a stabilized power source with a controlled switchgear.
SSCross2 POE 220
The structure is vibration and impact resistant. The housing is dust and moisture proof, the door is closed tightly. It includes a temperature regulation system, which ensures compensation for high and low temperatures. Bottom panel of the cabinet has a door with cable glands for connecting cables from external check point devices and networks. Switching and control check point equipment, a fan and a power source are located inside the housing and on the door. Inner equipment is securely fixed on DIN-rails and special brackets, all the necessary switching between the inner connectors is provided. All electric and telecommunication connections run through corresponding leakage current, overvoltage, short circuit and surge voltage protection devices. An industrial computer is included, as a computing module for the traffic monitoring system. An inbuilt heater protects the computer from low temperatures. A separate internal cabinet controller is provided to control the operating capacity of the inner and outer device and to remotely switch power on and power off.
Equipment
Functionality
System design
Switchboard cabinet
TLCross
TLCross
with traffic light line control equipment are designed to connect traffic monitoring systems equipment with the output power circuits of the traffic light road controller.
Download datasheets<<
Download datasheets<<
TLCross 4 and TLCross 8 switchboard cabinets with traffic light line control equipment are designed to connect traffic monitoring systems equipment with the output power circuits of the traffic light road controller. The connection is made with several voltage relays and an input/output device or an interface converter located inside the cabinets. Traffic light line signals are converted into discrete relay closed/open signals and then into a multiplexed data stream in the form of Ethernet messages.
TLCross
Cabinet structure is vibration and impact resistant. The housings are dust and moisture proof, the door is closed tightly. Bottom panel of the cabinet has a door with cable glands for connecting cables from external check point devices and networks.
Switching and converting equipment, and a power source are located inside the housing and on the door. Inner equipment is securely fixed on DIN-rails and special brackets, all the necessary switching between the inner connectors is provided. All electric and telecommunication connections run through corresponding leakage current, overvoltage, short circuit and surge voltage (lightning) protection devices.
Cabinets are mounted on a solid support (a pole, a lamp post, etc.) near the check point equipment. Sets of cables and elements for mounting on poles are included.
Switching and converting equipment, and a power source are located inside the housing and on the door. Inner equipment is securely fixed on DIN-rails and special brackets, all the necessary switching between the inner connectors is provided. All electric and telecommunication connections run through corresponding leakage current, overvoltage, short circuit and surge voltage (lightning) protection devices.
Cabinets are mounted on a solid support (a pole, a lamp post, etc.) near the check point equipment. Sets of cables and elements for mounting on poles are included.
Equipment
Functionality
System design
Switch device NCCross4
NCCross switch device is designed for switching of the power supply circuits and electrical control signals as part of the traffic monitoring and other video surveillance systems. NCCross4 ensures protection of the switched circuits and connected equipment from pulse interferences. The device is designed for outdoor installation and protects connections from adverse weather conditions.
NCCross4
It contains an interconnection board with switching elements (connectors) and pulse interference protection devices, inside a dust- and waterproof housing. Cables are lead in through special glands and a fitting for a 32 mm HDPE corrugated cable conduit.
Board indicators are provided to let the user know if the device is powered on and whether the connected equipment is functioning as expected.
The box is mounted on a solid support (a pole, a lamp post, etc.) near the check point equipment. Four 4 mm fastener holes in the box base, positioned as corner points of a 94×72 mm rectangle, for mounting on a support. Cable glands and a fitting included.
Board indicators are provided to let the user know if the device is powered on and whether the connected equipment is functioning as expected.
The box is mounted on a solid support (a pole, a lamp post, etc.) near the check point equipment. Four 4 mm fastener holes in the box base, positioned as corner points of a 94×72 mm rectangle, for mounting on a support. Cable glands and a fitting included.
