Weigh in motion system (WMS)
Weigh in motion system (WMS) is designed to automatically measure axle loads of a moving vehicle, calculate its gross mass, overall dimensions (length, width, height), axle spacing, count the number of wheels on an axle, determine a vehicle class, identify vehicle registration plate as well as make pictures of a vehicle.
Weigh in motion system is a set of measuring and technical equipment and consists of force-receiving modules (FM), vehicle detection indicators, dimension measurement module (DMM), module for positioning and counting wheel number (tire number) on an axle of a moving vehicle (EMPTY), vehicle photofixation and vehicle registration plate identification module (PIM), electronics cabinet (EC), data communication unit and special software.
- Force-receiving modules (FM)

- vehicle detection indicators(VC Factor)

- dimension measurement module (DIMM)

- module for positioning and counting wheel number (type number) on an axe of a moving vehicle (MP)

- vehicle photofixation and VRP identification module (PAM)

- electronics cabinet (EC)

- data communication unit and special software

WMS electronic cabinet (EC)
DIMM optical
Force-receiving modules (FM)
VC Factor
General PIM video cavera
Weigh in motion system is a set of measuring and technical equipment

Functions WMS

  • Measure vehicle speed and identife vehicle registration plate
    1
  • Determine date and time when a vehicle passes WMS, take pictures of a vehicle when its parameters are measured.
    2
  • Measure axle loads, loads of axle groups and gross vehicle mass
    3
  • Measure overall vehicle dimensions (length, width, height).
    4
  • Count the number of vehicle axles, measure vehicle axle spacing, count the number of wheels (tires) on a vehicle axle
    5
  • Determine a vehicle class (according to EUR 13 or RUS 12 classifications).
    6
  • Detect vehicles which violate the Road Transport Shipping Rules in terms of allowed vehicle weight, allowed vehicle axle loads and maximum allowed vehicle dimensions
    7
  • Vehicles database storage, vast reporting capabilities, integration with external intelligent systems.
    8
